Thermopile

Includes:

• Copper Coil – With screw clamps to hold a nail for the nail melting demonstration.
• Nails – Steel flat-headed nails 65 x 3 mm or 2½ x 1/8 inch, some with a central groove making the nail thinner at that point.
• Solid and Split Aluminium Rings-Two solid and one split for the ring-launching demonstration.
• Solder Trough – Effectively a single turn coil in the form of a circular trough. Approximately 300 mm of solder is formed into a 50 mm dia meter circle to lie in the trough.

Enables students to investigate nature and properties of electricity by using simple circuits which are easily constructed on a base board. The connector system uses P.C.B. strips with cut-out sections whose ends can easily be inserted in spring terminals, ensuring low contact resistance and ease of connection.
