Plotting Compass
Both sides glass, with needle pivoted between top and bottom glass plates, diameter 20 mm.
In Stock
In Stock
Related products
-
Magnetism
Variable Magnetic Field Coil
An enamelled copper wire solenoid is wound on a clear acrylic tube. The extreme ends of the solenoid are movable and the magnetic field can be varied by moving the extreme ends. 4mm sockets are provided to apply the current across the solenoid. Coil Diameter 60 mm, Length 350 mm.
PH41150 -
Magnetism
Ring Launcher
The ring launcher consists of a vertically mounted solenoid of thick copper wire with an iron core. The coil is energized with by pressing the push button on the panel. Two aluminum rings are supplied with the apparatus. These rings fit over the solenoid and are supported at some height above the base by adjustable collar. The behaviour of the rings when the coil is energized depends on the type of the ring placed over the coil at the time. The solid aluminum ring is propelled straight up while the slotted ring remains static, thus demonstrating the principle of electromagnetic induction as well as Lenz law.
PH41154
