Photodiode Module Holder

The straight conductor is mounted on the square rod. Solenoid with multiple turns acts as a straight conductor along the one open edge of the solenoid.

Specifications

• Wire gauge 21SWG.
• No. of turns 35.

The LDR module is mounted on the square rod. The LDR module is provided with terminals for easy connections.

A compact data display system with the ability to capture, process and display multiple sensor data.

SPECIFICATIONS:

• 3.5” Touch display interface to be able to select which sensor data to be displayed.
• 3 sensor data can be interfaced at a given point.
• The Compact Size of 175mm x 100mm x 40mm makes it handy to use.
• Powered by a Micro USB connector makes it is more versatile.
